Huaian Youzheng hydraulic machinery Co., LTD

Multi-way reversing valve, electronic control wireless distributor, hydraulic distributor, hydraulic lock of balance valve, overflow valve, manual valve, electronic control valve.

Multi-way reversing valve and distributor are combined valves composed of one-way valve gear pump, safety valve, oil inlet body, oil return body and multiple reversing valves, mainly manual reversing valves. It has the characteristics of high working pressure, compact structure, good safety valve performance, difficult leakage, reliable operation and good versatility.

Multi-way valve size: 8 10 12 15 20 25 32

Slide valve function: A.O.P.Y, etc.

Threaded interface: M18*1.5 M22*1.5 M27*2 M33*2

G3/8 G1/2 G3/4 G1 (three quarters, six quarters and one inch) can be customized as required.

Valve stem reset mode: spring automatic reset T or steel ball positioning W.

Pressure grade: 16 MPa, 20 MPa and 31.5 MPa are available.

A one-way valve is arranged inside the valve plate to prevent oil from flowing back. The oil inlet valve is equipped with an overflow valve to control the pressure of the whole system. According to customer requirements, overload valves can be installed to meet the load needs of different actuators. And an oil port with high pressure output connected in series to provide a power source for other hydraulic components. The reversing valve can be used for wrecker trailers, forklifts, sanitation vehicles, lifting and transportation machinery, mining machinery, agricultural machinery, rollover dump trucks, marine machinery, hoisting equipment and so on.
